This application allows you to solve a problem with your car electrical circuits. including :

1. STARTING & CHARGING SYSTEM

- BATTERY,IGNITION SWITCH,STARTER MOTOR,GENERATOR & PNP SWITCH CIRCUIT

2. ECM (ENGINE CONTROL MODULE)

- BATTERY POWER SUPPLY,GROUND,EI SYSTEM & CKP SENSOR CIRCUIT

- FUEL PUMP,FUEL CONNECTOR & CMP SENSOR CIRCUIT,INJECTOR & HEATED O2 SENSOR CIRCUIT

- MTIA,IAC,SENSOR (MAP,ECT,TP,IAT,KNOCK,ACP,HO2S,O2 & ROUGH ROAD) EGR VALVE,LEGR CIRCUIT & POWER STEERING PRESSURE SWITCH CIRCUIT

- EVAP CANISTER PURGE SOLENOID,CMP SENSOR,VGIS,CLUSTER & VSS CIRCUIT

- CLUSTER,FUEL PUMP & TCM CIRCUIT

- DLC,MIL LAMP & IMMOBILIZER CONTROL CIRCUIT & RON SWITCH CIRCUIT

3. TCM (TRANSMISSION CONTROL MODULE)

- POWER SUPPLY,GROUND,PNP SWITCH,BRAKE SWITCH & SOLENOID VALVE CIRCUIT

- SENSOR (INPUT SPEED,OUTPUT SPEED,TRANSMISSION FLUID TEMP),CLUSTER,DLC,ECM & HOLD MODE SWITCH CIRCUIT

- PNP SWITCH & CLUSTER CIRCUIT

4. AIR CONDITIONER

- AIR CONDITIONER CONTROL SWITCH,BLOWER MOTOR RESISTER & BLOWER MOTOR CIRCUIT

- AIR CONDITIONER CONTROL,INTAKE MOTOR SWITCH & AIR CONDITIONER COMPRESSOR CIRCUIT

5. FATC (FULL AUTOMATIC TEMPERATURE CONTROL)

- BLOWER MOTOR,INTAKE MOTOR,MODE MOTOR,MAX HIGH RELAY & POWER TR CIRCUIT

- SENSOR (AMBIENT,INCAR,SUN & WATER),AIR MIX DOOR MOTOR,A/C COMPRESSOR & ECM CIRCUIT

6. RADIATOR COOLING FAN CIRCUIT

7. HEAD LAMP & HEAD LAMP LEVELING DEVICE (HLLD) CIRCUIT

8. ILLUMINATION CIRCUIT

- ILLUMINATION CIRCUIT -- W/ DIMMER CONTROL

- LAMP (LICENSE PLATE & W/ FRONT / REAR PARKING) CIRCUIT

9. FRONT & REAR FOG LAMP CIRCUIT

10. HAZARD & TURN SIGNAL LAMP CIRCUIT

11. STOP LAMP,CENTER HIGH MOUNT STOP LAMP (CHMSL) & REVERSE LAMP CIRCUIT

12. TRUNK OPEN SWITCH,TRUNK LATCH SWITCH,TRUNK ROOM LAMP & HORN CIRCUIT

- DUAL HORN

- SIGNLE HORN

13. LAMPS (MAP & ROOM) CIRCUIT

- W/O SUN ROOF & W/O DECAY

- W/ SUN ROOF & W/O DECAY

14. CLOCK,CIGAR LIGHTER,ASHTRAY ILLUM.LAMP & EXTRA POWER JACK CIRCUIT

- M/T

- A/T

15. CHIME BELL,SEAT BELT & KEY REMIND SWITCH CIRCUIT

16. WIPER CIRCUIT

- W/O RAIN SENSOR & AIR CONDITIONER,FATC

- W/ RAIN SENSOR & AIR CONDITIONER,FATC

17. REAR WINDOW DEFROSTER & OSRV MIRROR HEATING SYSTEM CIRCUIT

18. ELECTRIC OSRV (OUTSIDE REAR VIEW) MIRROR CIRCUIT

19. FOLDING MIRROR UNIT CIRCUIT

20. POWER WINDOW CIRCUIT

- ONLY FRONT POWER WINDOW CIRCUIT

- FRONT & REAR POWER WINDOW CIRCUIT

21. CENTRAL DOOR LOCKING SYSTEM CIRCUIT

22. CLUSTER

- TEMPERATURE GAUGE,TACHOMETER,FUEL GAUGE,ODDOMETER,SPEEDOMETER & FUEL WARNING LAMP CIRCUIT

- WARNING (MIL,ABS,TCS,PARKING BRAKE & CHARGING) LAMP CIRCUIT

- WARNING (SSPS,AIR BAG,OIL PRESSURE & SEAT BELT) LAMP & HOLD MODE CIRCUIT

- INDICATOR LAMP (FRONT & REAR FOG) & DOOR OPENING WARNING LAMP CIRCUIT

- INDICATOR LAMP (TURN SIGNAL,HIGH BEAM & HAZARD) & ILLUMINATION LAMP CIRCUIT

23. AUDIO CIRCUIT

- W/O RDS

- W/ RDS

24. ABS (ANTI LOCK BRAKE SYSTEM)

- POWER SUPPLY,WHEEL SPEED SENSOR & BRAKE SWITCH CIRCUIT

- OIL FEEDING CONNECTOR,WARNING (ABS,TCS & BRAKE) LAMP & DLC CIRCUIT

25. AIR BAG (SDM: SENSING & DIAGNOSTIC MODULE) CIRCUIT

26. SUN ROOF CIRCUIT

27. SSPS (SPEED SENSITIVE POWER STEERING) CIRCUIT

28. IMMOBILIZER SYSTEM CIRCUIT

29. ANTI THEFT CONTROL SYSTEM CIRCUIT
